IMDvista BOCO SCAN - Bottle Scanning System Solution

We scan and measure your bottle inline

Easy and fast integration directly in your line.

  • Transparent, opaque, shiny and matte bottles
  • Precise calibrated inline measurement +/- 5 μm
  • Fast changeover with automatic product change – no mechanical size parts
  • Wide range of bottle designs
High performance / speed up to
700
parts per min
Pixel resolution / cam up to
3.4
for precise inspection

Functionality and Design

BOCO SCAN is the latest development in bottle inspection technology. Using high-resolution cameras and advanced illumination, BOCO SCAN is able to inspect the most complex bottle geometries, shapes and colors, regardless of whether the bottle is opaque HDPE or clear PET, shiny or matte.

IMD’s advanced V5 software includes reflection suppression, automatic setup wizard and Neuron artificial intelligence, allowing the complete bottle to be inspected while virtually eliminating false rejects.

BOCO SCAN offers precise thread measurements, for both HDPE and PET, by utilizing special cameras, lenses and lighting. The automatic change-over feature does not require and additional hardware when changing between bottles, regardless of the bottle material. The new BOCO SCAN is designed to easily fit over your existing line.

Precise Calibrated Measurement
Thread Measuring

First precise calibrated inline measurement +/- 5 μm

Fast Changeover with automatic product change - no mechanical parts
Fast Changeover

Fast changeover with automatic product change – no mechanical parts

Wide range of bottle designs
Great Variety

Wide range of bottle designs

Easy and fast integration in your existing produciton line
Easy Integration

Easy and fast integration in your existing production line

In Depth

A complete solution for your 100% bottle inspection and measuring – the efficient way of inline bottle inspection directly integrated into your bottle conveyors.

IMDvista BOCO SCAN
01

IMDvista VCC V5 – Vision Control Center – Based on same software as all IMDvista systems

02

100% Bottle inspection and precise calibrated inline measurement +/- 5 μm

03

Easy acess to all camera applications – on floor level

04

Bad bottle rejection right after inspection

05

Easy and fast integration in your existing production line

Your Benefits

First inline calibrated bottle inspection and measurement system brings your bottle inspection on a new level.

  • Fast self-learn teach in function with IMDvista V5 VCC for reflection suppression, automatic setup wizard and Neuron software with artificial intelligence
  • Calibrated measurement +/- 5 μm
  • High-resolution inspection for complex bottle geometries, shapes, colors and material as well  as transparent, opaque, shiny or matte bottles
  • Same system for several material types (PP, PET, PE, …)
  • Automated changeover between bottle types and easily fits over your existing line

Bottle Inspection

Choose your bottle inspection system from different options

Learn more about Bottle Inspection
